20 ASUS CUV266-D User’s Manual
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
5) Clear RTC RAM (CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS.
You can clear the CMOS memory of date, time, and system setup parameters by
erasing the CMOS RTC RAM data. The RAM data in CMOS, that include system
setup information such as system passwords, is powered by the onboard button
cell battery.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the battery.
3. Remove the jumper cap from pins 1-2, and place it over pins 2-3 (Clear
RTC) for a few seconds to short the jumper.
4. Replace the jumper cap to pins 1-2 (Normal).
5. Re-install the battery.
6. Plug the power cord and turn ON the computer.
7. Hold down the key during the boot process and enter BIOS setup to
re-enter data.
®
CUV266-D
0 1 0 1 0 1 0 1
CUV266-D Clear RTC RAM
1 2
CLRTC
Normal CLEAR RTC
2 3
(Default)
