2-10 ASUS M2N68 SE
2.3 Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving you an
overview of the basic system information.
2.3.1 System Time [xx:xx:xx]
Allows you to set the system time.
2.3.2 System Date [Day xx/xx/xxxx]
Allows you to set the system date.
2.3.3 Legacy Diskette A [1.44M, 3.5 in.]
Sets the type of floppy drive installed. Configuration options: [Disabled]
[360K, 5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.] [1.44M, 3.5 in.] [2.88M, 3.5 in.]
2.3.4 Storage Configuration
The Storage Configuration menu allows you to configure your storage device(s). Select an
item then press to display the sub-menu.
Onboard IDE Controller [Enabled]
Allows you to enable or disable the onboard IDE controller.
Configuration options: [Enabled] [Disabled]
Serial-ATA Devices [Enabled]
Allows you to disable or enable the Serial-ATA devices.
Configuration options: [Enabled] [Disabled]
SATA Mode select [SATA Mode]
Configuration options: [SATA Mode] [RAID Mode] [AHCI Mode]
Refer to section “2.2.1 BIOS menu screen” for information on the menu screen items and
how to navigate through them.
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
BIOS SETUP UTILITY
Main Advanced Power Boot Tools Exit
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
System Time [ 19 :34:30]
System Date [Wed 08/27/2008]
Legacy Diskette A [1.44M, 3.5 in.]
Storage Configuration
Primary IDE Master :[Not Detected]
Primary IDE Slave :[Not Detected]
SATA1 :[Not Detected]
SATA2 :[Not Detected]
SATA3 :[Not Detected]
SATA4 :[Not Detected]
System Information
