2-20 ASUS M4A78 PRO
Slot Power Limit, W [75]
Use the <+> and <-> keys to change the value or type the desired value using the numeric
keypad. The values range from 0 to 255.
Port #04/05/06/07/09/10 Features
Gen2 High Speed Mode [Disabled]
Configuration options: [Auto] [Disabled] [Software Initiated] [Advertised RC]
Link ASPM [Disabled]
Configuration options: [Disabled] [L0s] [L1] [L0s & L1]
NB-SB Port Features
NB-SB Link ASPM [Disabled]
Configuration options: [Disabled] [L1]
NP NB-SB VC1 Traffic Support [Disabled]
Configuration options: [Enabled] [Disabled]
Link Width [Auto]
Configuration options: [Auto] [x1 Mode.] [x2] [x4]
Primary Video Controller [GFX0-GPP-IGFX-PCI]
Allows you to select which graphics controller to use as the primary boot device.
Configuration options: [GFX0-GPP-IGFX-PCI] [GPP-GFX0-IGFX-PCI] [PCI-GFX0-GPP-
IGFX] [IGFX-GFX0-GPP-PCI]
NB Power Management Features [Auto]
Allows you to enable or disable the NorthBridge power management features.
Configuration options: [Auto] [Disable]
2.5.3 Onboard Devices Configuration
HD Audio Device [Enabled]
Allows you to enable or disable the HD Audio controller.
Configuration options: [Disabled] [Enabled]
Front Panel Select [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
Configuration options: [AC97] [HD]
Onboard LAN [Enabled]
Allows you to enable or disable the onboard LAN.
Configuration options: [Enabled] [Disabled]
Onboard LAN Boot ROM [Disabled]
Allows you to enable or disable the onboard LAN Boot ROM.
Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
