xi
Internal I/O connectors 3 x USB connectors support additional 6 USB ports
1 x IDE connector
1 x S/PDIF out header
1 x CPU fan connector
1 x chassis fan connector (3-pin)
1 x power fan connector
1 x COM connector
1 x Clear CMOS jumper
6 x SATA 6Gb/s connectors
1 x system panel connector
1 x high definition front panel audio connector front panel audio connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x Core Unlocker switch
1 x MemOK! button
Rear panel I/O ports 1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x Optical S/PDIF Out port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports (blue)
(USB 3.0 only for USB3 Edition)
8 x USB 2.0/1.1 ports (6 ports for USB3 Edition)
8-channel audio I/O ports
BIOS features 8 Mb Flash ROM, SPI, AMI BIOS, PnP, DMI 2.0, WfM2.0,
SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ
Flash 2, ASUS CrashFree BIOS 3
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Support DVD contents Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12 in x 8.4 in (30.5 cm x 21.3 cm)
M4A87TD specifications summary
* Specifications are subject to change without notice.
