8 Chapter 2: Hardware information
2.2 Motherboard layout
The audio and LAN features are optional. These components are
grayed out in the above motherboard layout.
FLOPPY1 HPANEL1
IR1
CD1
CPUFAN1
SiS650
HOST/
Memory
Controller
PS/2
T: Mouse
B: Keyboard
GAME_AUDIO
Mic
In
Line
Out
Line
In
AUX1
IDELED1
USB2 USBV2
P4S133-VM
®
SMARTCON1
FPAUDIO1
MODEM
ITE 8707F
Super I/O
2Mbit
Flash
BIOS
PCI Slot 1
ATX Power Connector
Primary IDE
Secondary IDE
Bottom:
USB1
USB2
Top:
RJ-45
2 3 0 1
Accelerated Graphics Port
(AGP)
USBV1
SiS961
MuTLOL
Media
I/0
SPDIF1
ATX12V1
Audio
Codec
ICS
1893Y
ASUS
Mozart
CHASFAN1
CLRRTC1
19.1cm (7.5in)
24.4cm (9.6in)
Socket 478
PCI Slot 2
PCI Slot 3
COM1
P
ARALLEL
PORT
VGA
CHAS_IN1
USB3
USBV3
DIMM Socket 1 (72-bit, 168-pin module) DIMM Socket 2 (72-bit, 168-pin module)
CR2032 3V
Lithium Cell
CMOS Power
JF1
FSJ1
LED1
BUZZER
