xiii
** Specifications are subject to change without notice.
*** Refer to www.asus.com for the complete list of supported PIKE cards.
Model Name Z9PE-D16-10G/DUAL Z9PE-D16-10G/SINGLE
Storage
SATA Controller
Intel ® C602-A:
4 SATA 3Gb/s ports; 2 SATA 6Gb/s ports
Intel ® RSTe (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI ® MegaRAID driver support software RAID 0, 1
&10)
(Linux/Windows)
SAS Controller
Optional kits***:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G HW RAID card
ASUS PIKE 2208 8-port SAS 6G HW RAID card
Graphic VGA Aspeed AST2300 + 16MB
Onboard I/O
Connectors
TPM Header 1
PSU Connector
- 24-pin SSI power connector + 8-pin SSI 12V
(For 95W or below CPU only)
- 24-pin SSI power connector + 8-pin SSI 12V
+ 8-pin SSI 12V (For 115W or above CPU only)
USB Connectors
1 x USB connector (Type A USB socket)
2 x USB pin header (up to 4 devices)
Fan Header 9 x 4 pin headers
SMBus 2
Chassis Intruder 1
Front LAN LED 2
Serial Port Header 2
Rear I/O
Connectors
SFP+ 2
VGA Port 1
External USB Port 2 x USB2.0
RJ-45
2 x GbE LAN
1 Management LAN
PS/2 KB/Mouse 1/1
Management
Solution
Software ASWM Enterprise
Out of Band
Remote
Management
ASMB6-iKVM for KVM-over-Internet
Monitoring
CPU Temperature
FAN RPM
Z9PE-D16-10G Series Specifications Summary
