2-17 ASUS Z77-A
CPU Power Phase Control [Standard]
Allows you to control the power phase based on the CPU’s demands.
Configuration options: [Standard] [Optimized] [Extreme] [Manual Adjustment]
DO NOT remove the thermal module when switching to Extreme and Manual Mode. The
thermal conditions should be monitored.
CPU Power Duty Control [T.Probe]
DIGI + VRM Duty control adjusts the current and thermal conditions of every component’s
phase. Configuration options:
[T. Probe]:
Select to maintain the VRM thermal balance.
[Extreme]: Select to maintain the current VRM balance.
CPU Current Capability [100%]
Allows you to configure the total power range, and extends the overclocking frequency range
simultaneously. Configuration options: [100%] [110%] [120%] [130%] [140%]
iGPU Load-line Calibration [Auto]
Allows you to set the iGPU Load-line Calibration. Configuration options: [Auto] [Regular]
[High] [Extreme]
The actual performance boost may vary depending on your CPU configuration.
iGPU Current Capability [100%]
Allows you to set the iGPU Current Capability. Configuration options: [100%] [110%] [120%]
[130%]
DO NOT remove the thermal module while changing the DIGI+ VRM related parrameters .
The thermal conditions should be monitored.
CPU Voltage [Offset Mode]
[Manual Mode] Allows you to set a fixed CPU voltage.
[Offset Mode]
Allows you to set the Offset voltage.
