1 - 2 6 1 - 2 6 1 - 2 6 1 - 2 6 1 - 2 6 C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n C h a p t e r 1 : P r o d u c t i n t r o d u c t i o n
4 . 4 . 4 . 4 . 4 . C P U a n d C h a s s i s f a n c o n n e c t o r s C P U a n d C h a s s i s f a n c o n n e c t o r s C P U a n d C h a s s i s f a n c o n n e c t o r s C P U a n d C h a s s i s f a n c o n n e c t o r s C P U a n d C h a s s i s f a n c o n n e c t o r s
( 4 - p i n C P U _ F A N 1 , 3 - p i n C H A _ F A N 1 )
( 4 - p i n C P U _ F A N 1 , 3 - p i n C H A _ F A N 1 ) ( 4 - p i n C P U _ F A N 1 , 3 - p i n C H A _ F A N 1 ) ( 4 - p i n C P U _ F A N 1 , 3 - p i n C H A _ F A N 1 ) ( 4 - p i n C P U _ F A N 1 , 3 - p i n C H A _ F A N 1 )
The fan connectors support cooling fans of 350mA~740mA (8.88W
max.) or a total of 1A~2.22A (26.64W max.) at +12V. Connect the fan
cables to the fan connectors on the motherboard, making sure that the
black wire of each cable matches the ground pin of the connector.
Do not forget to connect the fan cables to the fan connectors.
Insufficient air flow inside the system may damage the motherboard
components. These are not jumpers! DO NOT place jumper caps on the
fan connectors.
3 . 3 . 3 . 3 . 3 . S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 )
These connectors are for the Serial ATA signal cables for Serial ATA
hard disk drives.
Install the Windows ® 2000 Service Pack 4 or the Windows ® XP Service
Pack1 or later before using Serial ATA.
P5P800-MX
®
P5P800-MX SATA connectors
SATA2
GND
RSA
T
A_TXP2
RSA
T A_TXN2
GND
RSA
T A_RXP2
RSA
T
A_RXN2
GND
SATA1
GND
RSA
T A_TXP1
RSA
T
A_TXN1
GND
RSA
T A_RXP1
RSA
T
A_RXN1
GND
P5P800-MX
®
P5P800-MX Fan connectors
CPU_FAN1
CHA_FAN1
GND Rotation +12V
GND
CPU FAN PWR
CPU FAN IN
CPU FAN PWM
