ASUS M2V-X 2-3
2.2.3 Motherboard layout
Socket
AM2
20.5cm (8.0in)
30.5cm (12.0in)
VIA
K8T890
VT8237A
DDR2 DIMM_B1 (128 bit,240-pin module) DDR2 DIMM_A1 (128 bit,240-pin module) DDR2 DIMM_B2(128 bit,240-pin module) DDR2 DIMM_A2 (128 bit,240-pin module)
PCIEX16_1
PCIEX1_1
PCI1
PCI2
PCI3
PCI4
EATXPWR
ATX12V
AAFP
COM1
CD
FLOPPY USB56
PANEL
SB_PWR
USBPW2
CLRTC
CHASSIS
SATA2
SATA1
CHA_F
AN
SPDIF_OUT
CR2032 3V
Lithium Cell
CMOS Power
USB78
SEC_IDE
PRI_ID
E
CPU_FAN
KBPWR
USBPW1
PS/2KBMS
T: Mouse
B: Keyboard
Below:Mic In
Center:Line Out
Top:Line In
RJ-45
Top:
USB3
USB4
Bottom:
F_USB12
PA
RALLEL
PORT
SPDIF_O1
ALC660
4Mb
BIOS
LAN
SUPER I/O
M2V-X
