ASUS DSBF-D16 Series 4-21
Branch 0 Rank Sparing [Disabled]
Allows you to enable or disable the Branch 0 rank/DIMM Sparing feature. This item
does not appear when the Memory Branch Mode is set to [Sequential] and [Mirror].
Configuration options: [Disabled] [Enabled]
Branch 1 Rank Interleave [4:1]
Allows you to select the Branch 0 Rank Interleave. This item does not appear when
the Memory Branch Mode is set to [Sequential] and [Single channel 0].
Configuration options: [1:1] [2:1] [4:1]
Branch 1 Rank Sparing [Disabled]
Allows you to enable or disable the Branch 0 rank/DIMM Sparing feature. This item
does not appear when the Memory Branch Mode is set to [Sequential], [Mirror]
and [Single channel 0]. Configuration options: [Disabled] [Enabled]
Enhanced x8 Detection [Enabled]
Allows you to enable or disable the enhanced x8 DRAM UC error detection.
Configuration options: [Disabled] [Enabled]
Force ITK Config Clocking [Disabled]
Allows you to enable or disable the FBD configuration for ITK test suite.
Configuration options: [Disabled] [Enabled]
FBDIMM(s) Thermal Throttling [ASUS MemCool F]
Allows you to disable or set the thermal throttling control.
Configuration options: [Open Loop] [Closed Loop] [ASUS MemCool FAN] [Disabled]
• Set this item to [ASUS MemCool FAN] for a better fan management.
• The Open Loop Type appears when you set FBDIMM(s) Thermal Throttling
to [Open Loop] or [Closed Loop]
Open Loop Type [Best Performance]
Allows you to select the Open Loop Type.
Configuration options: [Best Performance] [Best Acoustic] [User Define]
Environment Temperature [25 ºC]
Allows you to select the Environment Temperature value.
Configuration options: [20 ºC]~[40 ºC]
Temperature Rise [25 ºC]
Allows you to select the Temperature Rise value.
Configuration options: [10 ºC]~[30 ºC]
FBDIMM(s) Air Flow [2.0]
Allows yout to select the Air Flow value.
Configuration options: [1.0] [1.5]~[4.5] [5.0]
The following items appear when you set the Open Loop Type to [User Define].
