Asus Terminator Tualatin - Manual (Page 16)

16 Chapter 2: Basic Installation
Thumbscrew
2.1 Remove the Cover
The chassis cover is secured by a thumbscrew located on the rear
panel.
Follow these steps to remove the
chassis cover.
1. Turn the captive thumbscrew
counter-clockwise to release
the cover. You don’t have to
remove the thumbscrew from
the chassis.
2. Place your hands on both
corners of the front panel, just
beside the CD-ROM frame.
With the rest of your fingers
pulling forward from both
sides, push on the CD-ROM
area with your thumbs until
the cover tilts forward.
3. While supporting the front
panel with one hand, place
your other hand on the top
rear edge of the cover and
carefully lift the cover from the
chassis.
