2-10 ASUS P5QL-VM DO/SI
ME Subsystem Configuration
ASF Support [Enabled]
Allows you to enable or disable the Alert Standard Format (ASF).
Configuration options: [Disabled] [Enabled].
ME HECI Configuration
ME-HECI [Enabled]
When set to [Enabled], Host Embedded Communication Interface (HECI) provides
an interface for the exchange of message between the host software and the ME
firmware. Configuration options: [Disabled] [Enabled].
ME-IDER [Disabled]
Allows you to enable or disable the IDE Redirection interface by which the remote
management console is able to direct the client PC to boot. Configuration options:
[Disabled] [Enabled].
ME-KT [Disabled]
When set to [Enabled], the KT function helps redirect keyboard and POST message
to the remote management console and thus facilitates the control of the client
machine through the network. Configuration options: [Disabled] [Enabled].
Configure Intel AMT Parameters
ME BIOS Extension [Enabled]
Allows you to enable or disable ME BIOS Extension.
Configuration options: [Enabled] [Disabled].
The Intel ® Active Management Technology requires the Intel ® AMT-enabled software. Also,
the platform must be connected to a power source and an active LAN port.
MEBx Setup Prompt [Hidden]
Allows you to select to display or hide the ME BIOS Extension text during POST.
Configuration options: [Hidden] [Displayed].
POST Delay (in Seconds) [None]
Allows you to set the time delay during POST. Configuration options: [None] [1
Second] [3 Second] [Second]
This motherboard supports Intel ® DVMT 5.0 Technology whose maximum graphics memory
size in total varies with the system memory size in total and the operating system. Refer to
the following table for details.
System Memory
Maximum Total Graphics Memory
Windows ® XP Windows ® Vista™
1GB to < 1.5GB 512MB 552MB
1GB to < 2GB 768MB 808MB
2GB to < 3GB 1024MB 1320MB
3GB to < 4GB — 1832MB
4GB and above — 1849MB
