1.5.4 Layout contents
Slots Page
1. DDR2 DIMM slots 1-16
2. PCI slots 1-25
3. PCI Express x1 slot 1-25
4. PCI Express x16 slot 1-25
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC) 1-26
2 . USB device wake-up (3-pin USBPW) 1-27
Rear panel connectors Page
1. PS/2 mouse port (green) 1-28
2 . Parallel port 1-28
3 . LAN (RJ-45) port 1-28
4 . Line In port (light blue) 1-28
5. Line Out port (lime) 1-28
6 . Microphone port (pink) 1-28
7 . USB 2.0 ports 1 and 2 1-29
8. USB 2.0 ports 3 and 4 1-29
9. Serial port 1-29
10 . PS/2 keyboard port (purple) 1-29
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 1-30
2. Speaker connector (4-pin SPEAKER) 1-30
3. IDE connector (40-1 pin PRI_IDE) 1-31
4. ICH7 Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 1-32
5. USB connectors (10-1 pin USB56, USB78) 1-33
6. Optical drive audio connector (4-pin CD) 1-33
7. CPU, and chassis fan connectors (4-pin CPU_FAN, 3-pin CHA_FAN) 1-34
8. Chassis intrusion connector (4-1 pin CHASSIS) 1-35
9. Front panel audio connector (10-1 pin AAFP) 1-35
10. ATX power connectors (24-pin EATXPWR, 4-pin ATX 12V) 1-36
11. System panel connector (20-8 pin PANEL) 1-37
