1-4 Chapter 1: Product introduction
1.4 Overview
Before you install the P4SGL-VM motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Motherboard components
The following are the major components of the P4SGL-VM motherboard
as pointed out in the picture on page 1-5.
1. ATX 12V connector
2. CPU socket
3. North Bridge controller
4. ATX power connector
5. DDR DIMM sockets
6. IDE connectors
7. South Bridge controller
8. ASUS ASIC
9. Onboard LED
10. Floppy disk connector
11. Flash EEPROM
12. Super I/O controller
13. PCI slots
14. AC’97 CODEC (on audio
models only)
15. LAN PHY (on LAN models
only)
16. PS/2 mouse port
17. RJ-45 port (on LAN models
only)
18. Parallel port
19. Game/MIDI port (on audio
models only)
20. Microphone jack (pink)(on
audio models only)
21. Line In jack (blue)(on audio
models only)
22. Line Out jack (lime)(on audio
models only)
23. VGA port
24. Serial Port
25. USB ports
26. PS/2 Keyboard port
See page 1-6 for a brief description of each component. Refer to
Chapter 2 for more information on the motherboard jumpers and
connectors.
