2-8 ASUS P7H55-M/USB3
2.2.5 Submenu items
A solid triangle before each item on any menu screen means that the item has a submenu.
To display the submenu, select the item and press .
2.2.6 Configuration fields
These fields show the values for the menu items. If an item is user- configurable, you can
change the value of the field opposite the item. You cannot select an item that is not user-
configurable.A configurable field is enclosed in brackets, and is highlighted when selected. To
change the value of a field, select it then press to display a list of options. Refer to
2.2.7 Pop-up window.
2.2.7 Pop-up window
Select a menu item then press
to display a pop-up
window with the configuration
options for that item.
2.2.8 Scroll bar
A scroll bar appears on the right
side of a menu screen when there
are items that do not fit on the
screen. Press the /
arrow keys or / keys to display the other items on the screen.
2.2.9 General help
At the top right corner of the menu screen is a brief description of the selected item.
2.3 Main menu
When you enter the BIOS Setup program, the Main menu screen appears, giving you an
overview of the basic system information.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2010, American, American Megatrends, Inc.
P7H55-M/USB3 BIOS Setup
Main Ai Tweaker Advanced Power Boot Tools Exit
Suspend Mode [Auto]
ACPI 2.0 Support [Enabled]
ACPI APIC support [Enabled]
Anti-Surge Support [Enabled]
APM Configuration
Hardware Monitor
If enabled, system
will have uvp or ovp
protection.
Options
Disabled
Enabled
Pop-up window
Scroll bar
Version 0306
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
P7H55-M/USB3 BIOS Setup
Main Ai Tweaker Advanced Power Boot Tools Exit
System Time [ 22 :40:51]
System Date [Fri 01/18/2002]
Language [English]
SATA1 :[Not Detected]
SATA2 :[Not Detected]
SATA3 :[Not Detected]
SATA4 :[Not Detected]
SATA5 :[Not Detected]
SATA6 :[Not Detected]
Storage Configuration
3rd Party Storage Configuration
System Information
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a field.
Use [+] or [-] to
configure system time.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Version 0306
