ASUS P8Z77-V LE PLUS 2-3
Chapter 2
Connectors/Jumpers/Slots Page
1. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1/2/3) 2-25
2. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-27
3. EPU LED (EPU_LED) 2-21
4. EPU switch 2-18
5. TPU switch 2-17
6. TPU LED (TPU_LED) 2-21
7. Intel ® CPU socket 2-4
8. DDR3 DIMM sockets 2-5
9. DRAM LED 2-20
10. MemOK! button 2-16
11. USB 3.0 connector (20-1 pin USB3_34) 2-26
12. Marvell ® Serial ATA 6.0 Gb/s connectors (7-pin SATA 6G_E1 [navy blue]) 2-27
13. Intel ® Z77 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1/2 [gray]) 2-22
14. Intel ® Z77 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1~4 [blue]) 2-23
15. Onboard LED (SB_PWR) 2-20
16. BIOS Flashback LED (FLBK_LED) 2-21
17. Clear RTC RAM (3-pin CLRTC) 2-15
18. System panel connector (20-8 pin PANEL) 2-28
19. BIOS Flashback button (BIOS_FLBK) 2-19
20. USB 2.0 connectors (10-1 pin USB3~10) 2-24
21. Serial port connectors (10-1 pin COM1) 2-26
22. Front panel audio connector (10-1 pin AAFP) 2-24
23. Digital audio connector (4-1 pin SPDIF_OUT) 2-25
