Asus TW100-E5 iQuadro - Manual (Page 97)

ASUS TW100-E5 5-9
Clearing a disk MBR
To clear disk MBR
1. From the Array List screen, use the up or down arrow keys to select a RAID
array, and then press . The RAID Array details appear.
A new set of navigation keys is displayed on the bottom of the screen.
2. Press to clear disk MBR. The following confirmation message appears.
Take caution in using this option. All data on the RAID drives will be lost!
3. Press to clear the disk MBR or press to cancel.
[R] Rebuild [D] Delete [C] Clear MBR [V] remove Vol [ENTER] Return
Array 4 : NVIDIA MIRROR 149.04G
- Array Detail -
RAID Mode: Mirrored
Striping Width: 1 Striping Block: 64K
Port Index Disk Model Capacity
0.0 0 WDC1600AAJS-22PSA0 149.05G
0.1 1 WDC1600AAJS-22PSA0 149.05G
Clear MBR?
[ENTER] OK [ESC] Cancel
