Entering the nvidia, Mediashield bios raid utility – Asus TW100-E5 iQuadro User Manual
Page 92
5-4
Chapter 5: RAID configuration
Entering the NVIDIA
®
MediaShield BIOS RAID utility
To enter the NVIDIA
®
MediaShield BIOS RAID utility
1. Boot up your computer.
2. During POST, press
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.
At the bottom of the screen are the navigation keys. These keys allow you to move
through and select menu options.
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
MediaShield BIOS Apr 25 2008
- Define a New Array -
RAID Mode:
Mirrored
Striping Block:
Optimal
Free Disks
Array Disks
Port Disk Model Capacity Port Disk Model Capacity
0.0. ST3160812AS 149.04GB
0.2. ST3160812AS 149.04GB
0.1. ST3160812AS 149.04GB
[←] Del
