5-24 Chapter 5: RAID configuration
5.4.2 RAID 1E/10 volume
The RAID 1E/10 supports three to ten disks, or seven mirrored disks plus two hot spare
disks.
Use odd numbers of hard disk drives to create a RAID 1E volume; use even numbers of
hard disk drives to create a RAID 10 volume.
To create a RAID 1E/10 volume:
1. Follow steps 1–4 of the section RAID 1E/10 volume.
2. On the Select New Volume Type screen, use the arrow keys to select Create RAID
1E/10 Volume then press .
Esc = Exit Menu F1/Shift+1 = Help
Enter = Choose volume type to create
LSI Corp Config Utility v7.29.00.00 (2012.11.12)
Select New Volume Type -- SAS2308-2
Create RAID 1 Volume Create a RAID 1 volume
consisting of 2 disks plus up to 2
optional hot spares. ALL DATA on
volume disks will be DELETED!
Create RAID 1E/10 Volume Create a RAID 1E or RAID 10 volume
consisting of 3 to 10 disks including up
to 2 optional hot spares. ALL DATA on
volume disks will be DELETED!
Create RAID 0 Volume Create a RAID 0 volume consisting of
2 to 10 disks. ALL DATA on
volume disks will be DELETED!
