xi
P5B Deluxe specifications summary
(continued on the next page)
CPU LGA775 socket for Intel ® Core™2 Quad /
Core™2 Extreme / Core™2 Duo / Pentium ® Extreme /
Pentium ® D / Pentium ® 4 / Celeron ® D Processors
Compatible with Intel ® 05B/05A/06 processors
Intel ® Hyper-Threading Technology ready
* Refer to www.asus.com for Intel CPU support list
Chipset Intel ® P965 / ICH8R with Intel ® Fast Memory Access
Technology
System Bus 1066 / 800 / 533 MHz
Memory 4 x DIMM, max. 8GB, DDR2 800 / 667 / 533 MHz, non-
ECC, un-buffered memory
Dual channel memory architecture
* Refer to www.asus.com or user manual for Memory
QVL (Qualify Vendor List)
Expansion Slots 2 x PCI-E x16 (blue @ x16 mode, black @ x4 or x2
mode) supports CrossFire technology
1 x PCI-E x1 (x1 or disabled mode)
3 x PCI 2.2
Storage Southbridge
- 6 x SATA 3.0 Gb/s ports
- Intel Matrix Storage Technology supports RAID 0, 1,
5 and 10.
JMicron
® JMB363 PATA and SATA controller
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x Internal SATA 3.0 Gb/s port
- 1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
- Support SATA RAID 0, 1 and JBOD (by 1 x External
SATA and 1 x Internal SATA)
LAN Dual Gigabit LAN controllers, both featuring AI NET2
Marvell ® PCI-E and PCI Gigabit LAN controllers
Audio ADI ® AD1988B 8-channel High Definition Audio CODEC
- Support Jack-Sensing, Enumeration, Multi-streaming
and Jack-Retasking
- Coaxial / Optical S/PDIF out ports at back I/O
- ASUS Noise Filter
- ASUS Array Mic
- DTS Connect™
Wireless LAN (WiFi-AP
Edition Only)
ASUS WiFi-AP Solo
54 Mbps IEEE 802.11g and backwards compatible with
11 Mbps IEEE 802.11b
- Software Access point mode
- Station mode : Infrastruceure mode and Ad-Hoc mode
