1-6 Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the motherboard, familiarize yourself with its physical
configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Major components
The following are the major components of the P4P800S-E Deluxe
motherboard as pointed out in the picture on page 1-7.
1. ATX12V power connector
2. CPU socket
3. North Bridge controller
4. DDR DIMM sockets
5. ATX power connector
6. Super I/O controller
7. Floppy disk connector
8. IDE connectors
9. AGP 8X slot
10. SATA connectors
11. Flash ROM
12. Speech controller
13. COM2 connector
14. South Bridge controller
15. Standby power LED
16. Wi-Fi slot
17. IEEE 1394 controller
18. PCI slots
19. Audio CODEC
20. Gigabit LAN controller
21. PS/2 mouse port
22. Parallel port
23. IEEE 1394 port
24. RJ-45 port
25. Line In jack
26. Line Out jack
27. Microphone jack
28. USB 2.0 ports 3 and 4
29. USB 2.0 ports 1 and 2
30. Serial port
31. S/PDIF out port
32. PS/2 keyboard port
See page 1-8 for the specifications of each component. Refer to Chapter 2 for
detailed information on the components.
