Asus GigaX2124X/C - Manual (Page 24)

GigaX Series L2 Managed Switch User’s Guide
24
4 Management with the Web Interface
The switch provides Web pages that allow switch management through the
Internet. The program is designed to work best with Microsoft Internet
Explorer® 5.5, or later versions. NOTE: Netscape is not supported.
4.1 Log into Web user interface
1. From a PC, open your web browser, type the following in the web
address (or location) box, and press :
http://192.168.1.1
This is the factory default IP address for the switch. A login screen
displays, as shown in Figure 8.
Figure 8. Configuration manager login screen
Login is not required if you do not enable Web authentication
access (see 3.3.2)" ʳ
ʳ
2. Enter your user name and password, then click .
