GigaX Series L2 Managed Switch User Guide
16
2.3 Rear Panel
The switch rear panel contains the ports for the data and power
connections.
Figure 3. Rear panel
No. Label Description
1 Power Connector Connects to the supplied power cord
2 RPS Redundant Power Supply connector
3 FAN1 – FAN2 Replaceable system fans
2.4 Technical specifications
Table 2. Technical specifications
Physical Dimensions 43.5mm(H) X 444 mm(W) X 265mm(D)
Input Consumption Power
100-240V AC/2.5A 50-60Hz < 90 watts
Input Output Redundant Power
Supply (RPS)
100-240V AC/1.8A 50-60Hz 12V DC/12.5A
Operating Storage
Temperature -10 to 50 (14 t к o
122 )
л
-40 - 70 к
(-40 to 158 )
л
Humidity 15 to 90% 0 to 95%
Environmental Ranges
Altitude up to 10,000 ft
(3,000m) 40,000 ft
(12,000m)
Dimensions Voltage and Current Speed: Replaceable Fans
40 x 40 x 20 mm 12VDC, 0.13A 8200RPM
