ASUS M5A87 2-17
Channel Interleaving [Auto]
Allows you to enable the channel memory interleaving.
Configuration options: [Disabled] [Address bits 6] [Address bits 12] [Auto]
[XOR of Address bits [20:16, 6]] [XOR of Address bits [20:16, 9]]
Enable Clock to All DIMMs [Disabled]
Enables unused Clocks to DIMMs even though memory slots are not populated. Configuraiton
options: [Enabled] [Disabled]
MemClk Tristate C3/ATLVID [Disabled]
Allows you to enable or disable MemClk Tri-Stating during C3 and Alt VID.
Configuration options: [Disabled] [Enabled]
Memory Hole Remapping [Enabled]
Allows you to enable or disable memory remapping around memory hole.
Configuration options: [Disabled] [Enabled]
DCT Unganged Mode [Always]
Allows you to select the unganged DRAM mode (64-bit width).
Configuration options: [Auto] [Always]
Power Down Enable [Disabled]
Allows you to enable or disable DDR power down mode.
Configuration options: [Disabled] [Enabled]
ECC Configuration
ECC Mode [Disabled]
Enables or disables the DRAM ECC that allows the hardware to report and correct memory errors
automatically. Configuration options: [Disabled] [Basic] [Good] [Super] [Max] [User]
Internal Graphics
Primary Display Adapter [GFX-GPP-PCI]
Selects the primary display adapter. Configuration options: [GFX-GPP-PCI] [GPP-GFX-PCI]
[PCI-GFX-GPP]
GFX: primary video controller on a PCIe x16 slot
GPP: primary video controller on a PCIe x1 slot
PCI: primary video controller on a PCI slot
2.5.3 Onboard Devices Configuration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address. Configuration options: [Disabled]
[3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses. Configuration options: [Disabled] [378]
[278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode. Configuration options: [Normal] [EPP] [ECP]
[EPP+ECP]
