ASUS P7P55D LE 2-19
HDA Controller [Enabled]
[Enabled] Enables the High Definition Audio Controller.
[Disabled] Disables the controller.
Front Panel Type [HD Audio]
[AC97] Set the front panel audio connector (AAFP) mode to legacy AC’97
[HD Audio] Set the front panel audio connector (AAFP) mode to high-
definition audio.
Realtek LAN [Enabled]
[Enabled] Enables Realtek LAN Controller
[Disabled] Disables Realtek LAN Controller.
LAN Boot ROM [Disabled]
This item appears only when you enable the previous item(s).
[Disabled] Disables Realtek LAN Boot ROM.
[Enabled] Enables Realtek LAN Boot ROM.
J-Micron eSATA/PATA Controller [IDE Mode]
[Disabled] Disables the J-Micron controller.
[IDE Mode] Set to [IDE Mode] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[AHCI Mode] Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advabced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
2.5.3 Onboard Devices Configuration
Onboard Devices Configuration
HDA Controller [Enabled]
Front Panel Type [HD Audio]
Realtek LAN [Enabled]
LAN Boot ROM [Disabled]
J-Micron eSATA/PATA Controller [IDE Mode]
Serial Port1 Address [3F8/IRQ4]
BIOS SETUP UTILITY
Advanced
Options
Enabled
Disabled
