Chapter 2, Layout contents – Asus P8C WS User Manual
Page 21
ASUS P8C WS
2-3
Chapter 2
Layout contents
Connectors/Jumpers/Switches/Slots
Page
1.
LGA1155 CPU Socket
2-4
2.
Power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-26
3.
DDR3 DIMM slots
2-5
4.
CPU, chassis, and power fan connectors (4-pin CPU_FAN,
4-pin CHA_FAN1-3, 3-pin PWR_FAN)
2-22
5.
MemOK! switch
2-11
6.
USB 3.0 connector (20-1 pin USB3_12)
2-20
7.
Intel
®
C216 Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_1-2 [gray])
2-17
8.
Intel
®
C216 Serial ATA 3.0 Gb/s connectors
(7-pin SATA3G_3–6 [blue])
2-18
9.
Standby Power LED
2-13
10.
System panel connector (20-8 pin PANEL)
2-27
11.
Clear RTC RAM (3-pin CLRTC)
2-15
12.
USB 2.0 connectors
(Type A: 10-1 pin USB1314; Type B: USB11/ USB12)
2-19
13.
Parallel port connector (26-1 pin LPT1)
2-20
14.
TPM connector (20-1 pin TPM)
2-24
15.
Serial port connector (10-1 pin COM1)
2-23
16.
Digital audio connector (4-1 pin SPDIF_OUT)
2-21
17.
IEEE 1394a port connector (10-1 pin IE1394_2)
2-21
18.
GPU Boost Switch
2-10
19.
EPU Switch
2-9
20.
Chassis Fan control setting (3-pin CHAFAN_SEL)
2-16
21.
Front panel audio connector (10-1 pin AAFP)
2-23
