P8C WS specifications summary
CPU LGA1155 socket for Intel ® 2 nd / 3 rd Generation Core™ i3 desktop processor
LGA1155 socket for Intel ® Xeon ® E3-1200/ 12x5 v2 series processor
Supports 32nm / 22nm CPU
* Supports Intel ® Turbo Boost technology 2.0.
** Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® C216 Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 1600 / 1333 MHz, ECC non-ECC, un-buffered
memory
Dual-channel architecture
Supports Intel ® Extreme Memory Profile (XMP)
**Refer to www.asus.com or this user manual for the Memory QVL (Qualified
Vendors Lidts)
Expansion
slots
1 x PCIe 3.0 x16 (at x16 or x8) (blue)
1 x PCIe 3.0 x16 (at x8) (black)
2 x PCIe 2.0 x16 (at x4) (white)
1 x PCIe 2.0 x1 (at x1)
1 x PCI
VGA
Output
DVI-I port
Supports DVI with max. resolution 1920 x 1200 at 60Hz
Maximum shared memory of 1GB
Multi-GPU
support
Supports ATI ® Quad-GPU CrossFireX™ Technology
Storage Intel ® C216 Chipset:
- 2 x SATA 6.0 Gb/s ports(gray)
- 4 x SATA 3.0 Gb/s ports(blue)
- Intel ® Rapid Storage Technology supports RAID 0, 1, 5, and 10
* Supports on Intel ® Smart Response Technology, Intel® Rapid Start
Technology, Intel ® Smart ConnectTechnology *
** Supports on Intel ® Core™ processor family with Windows 7 operating
systems.
LAN 2*Intel ® 82574L GbE LAN
- Support teaming function
USB Intel ® C216 Chipset:
- 4 x USB 3.0 ports (2 ports at mid-board, 2 ports at back panel)
- 10 x USB 2.0 ports (4 ports at mid-board, 6 ports at back panel)
1394 VIA VT6308S controller supports 2 x 1394a port
Audio Realtek ® ALC892 8-channel High Definition Audio CODEC
- BD audio layer content protection
- Supports Jack-Detection, Multi-streaming and Front Panel Jack-Retasking
- Optical S/PDIF out ports at back I/O
Workstation
Unique
Features
4 PCIe x 16 slots
G.P. Diagnosis Card bundled
Quick Gate: 1 vertical USB 2.0 on board
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI
2.0a, Multi-language BIOS, ASUS EZ Flash Utility, ASUS CrashFree BIOS 3
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
(continued on the next page)
