xv
MAXIMUS IV GENE-Z/GEN3 specifications
summary
CPU LGA1155 socket for 2nd Generation Intel ® Core™ i7/
Core™ i5/Core™ i3/Pentium/Celeron Processors Core™ i5/Core™ i3/Pentium/Celeron Processors
Supports 32nm/22nm CPU
Supports Intel ® Turbo Boost Technology 2.0
*The Intel ® Turbo Boost Technology 2.0 support depends
on the CPU types. on the CPU types.
**Refer to www.asus.com for Intel CPU support list
Chipset Intel ® Z68 Express Chipset
Memory Dual channel memory architecture
4 x DIMM, max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/
1866(O.C.)/1600/1333MHz, non-ECC, un-buffered
memory
* Supports Intel ® Extreme Memory Profile (XMP)
**Hyper DIMM support is subject to the physical
characteristics of individual CPUs. Some hyper DIMMs
only support one DIMM per channel.
*** Due to CPU behavior, DDR3 2200/2000/1800 MHz
memory module will run at DDR3 2133/1866/1600
MHz frequency as default.
**** Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lidts).
Expansion Slots 2 x PCIe3.0/2.0 x16 slots (single at x16 or dual at x8/x8
mode)
1 x PCIe2.0 x4 slot
* Actual PCIe speed depends on Installed CPU type. Actual PCIe speed depends on Installed CPU type.
Multi-GPU Technology Support NVIDIA ® SLI™ / ATI CrossFireX™ Technology Technology Technology
Supports LucidLogix ® Virtu™ Technology* Technology* Technology*
* LucidLogix LucidLogix ® Virtu™ supports Windows ® 7 operating
systems.
Storage Intel ® Z68 Express Chipset built-in:
- 2 x SATA 6Gb/s ports (Red)
- 4 x SATA 3Gb/s ports (Gray)
- Intel ® Rapid Storage Technology supports RAID 0,
1, 5 and 10
- Supports Intel ® Smart Response Technology* on
2nd generation Intel ® Core™ processor family
* Intel ® Smart Response Technology supports
Windows ® 7/ Vista operating systems.
JMicron ® 362 controller:
- 2 x External SATA 3Gb/s ports at rear (SATA On-
the-Go)
* These SATA ports are for data hard drives only. ATAPI
devices are not supported.
LAN 1 x Intel ® Gigabit LAN
(continued on the next page)
