background image

ix

P8H77-V specifications summary

(continued on the next page)

CPU

LGA1155 socket for Intel

®

3rd/2nd Generation Core™ i7 / Core™ i5 /

Core™ i5 /

Core™ i3 / Pentium

®

/

Celeron

®

Processors

Supports 22/32nm CPU

Supports Intel

®

Turbo Boost Technology 2.0

* The Intel

®

Turbo Boost Technology 2.0 support depends on the CPU

types.

** Refer to www.asus.com for Intel CPU support list

Chipset

Intel

®

H77 Express Chipset

Memory

4 x DIMMs, max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/

1866(O.C.)/1600/1333/1066 MHz, non-ECC, un-buffered memory

Dual channel memory architecture

Supports Intel

®

Extreme Memory Profile (XMP)

* DDR3 1600 MHz and higher memory frequency is supported by Intel

®

3rd generation processors.

** Due to the CPU behavior, DDR3 2133/1866 MHz memory module will

run at DDR3 2000/1800 MHz frequency as default.

*** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors

List).

**** When you install a total memory of 4GB capacity or more,

Windows

®

32-bit operating system may only recognize less than

3GB. We recommend a maximum of 3GB system memory if you

are using a Windows

®

32-bit operating system.

Expansion slots

1 x PCI Express 3.0* x16 slot [blue] (at x16 mode)

1 x PCI Express 2.0 x16 slots [black] (at x4 mode, compatible with

PCIe x1 and x4 devices)

2 x PCI Express 2.0 x1 slots

3 x PCI slots

* PCIe 3.0 speed is supported by Intel

®

3rd generation Core™

processors.

VGA

Integrated graphics processor - Intel

®

HD Graphics support

Multi-VGA output support: HDMI, DisplayPort, DVI-D, RGB ports

Supports HDMI with max. resolution of 1920 x 1200 @60Hz

Supports DisplayPort 1.1a with max. resolution of 2560 x 1600 @60Hz

Supports DVI with max. resolution of 1920 x 1200 @60Hz

Supports RGB with max. resolution of 2048 x 1536 @75Hz

Supports Intel

®

InTru™ 3D/Quick Sync Video/Clear Video HD

Technology/Insider™

Maximum shared memory of 1696 MB

Multi-GPU support

Supports ATI

®

Quad-GPU CrossFireX™ Technology

Supports Lucidlogix

®

Virtu MVP™ Technology*

* LucidLogix

®

Virtu MVP™ supports Windows

®

7 operating systems.

Storage

Intel

®

H77 Express Chipset

- 2 x SATA 6.0 Gb/s ports (gray) with RAID 0, 1, 5, 10 support

- 4 x SATA 3.0 Gb/s ports (blue) with RAID 0, 1, 5, 10 support

- Intel

®

Rapid Storage Technology supports RAID 0, 1, 5, and 10

- Supports Intel

®

Smart Response Technology, Intel

®

Rapid Start

Technology, Intel

®

Smart Connect Technology*

* Supports on Intel

®

Core™ processor family with Windows

®

7

operating systems.

LAN

Qualcomm Atheros

®

8161 PCIe Gigabit LAN controller
