-2 Chapter : BIOS setup
4.4.3 Onboard Devices Configuration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Configuration options: [Disabled] [2F8/IRQ3] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to set the BIOS selection mode for Serial Port2.Configuration
options: [Normal] [IrDA][ASK IR]
The following items appear when the Serial Port2 Mode is set to IrDA or ASK IR.
IR I/O Pin Selec [SINB/SOUTB]
Allows you to select receiver or transmit pin for Serial Port2 (IR Mode).
Configuration options: [SINB/SOUTB] [IRRX/IRTX]
IR Duplex Mode [Half Duplex]
Allows you to select full or half duplex for Serial Port2 (IR Mode).
Configuration options: [Half Duplex] [Full Duplex]
Configure Win627THG Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Configure Onboard Device
Onboard BCM5721A LAN [Enabled]
Onboard BCM5721B LAN [Enabled]
Onboard LAN BootROM [Disabled]
Allows BIOS to
Select Serial
Port1 Base
Addresses.
MCP55(SB) to K8(CPU) LinkWidth [16 16 ]
Sets the Hyper Transport width.
Configuration options: [8 8 ] [16 16 ]
