the LED description of the board. The test bed has seven LED indicator lamps for status display. Four
lamps indicate the statuses of 10 Base-T Ethernet Rx, Tx, Collision/Link and Act. Next lamp indicates
statuses of receive and transmit of the serial port for data communication. Next two lamps indicate the
system ready status and the system power-on status.
For the installation, users will have to plug in the NEMO10 module to the test bed considering the
interface pin direction. Figure 2-2 is a picture representing the dimensional factors and the layout of
the test bed, whereas the Figure 2-3 is the one that shows the picture of the NEMO10-SK after the
installation of the NEMO10 and the test bed.
Table 2-2 Pinouts for the NEMO10 test bed interface
Table 2-3 LEDs on the test bed
Pin NO.
Description
1
GND
2
Reset (High Active)
3
LED (Ethernet Tx)
4
LED (Ethernet Rx)
5
LED (Ethernet Link/Collision)
6
Ethernet Tx-
7
Ethernet Tx+
8
Ethernet Rx+
9
Ethernet Rx-
10
Vcc
11
LED (Ready)
12
LED (Ethernet Act)
13
Vcc
14
Console/Data switch
(High: Data, Low: Console)
15
Serial DSR
16
Serial CTS
17
Serial DTR
18
Serial RTS
19
Serial Rx
20
Serial Tx
21
Factory Reset switch
(Low Active)
22
GND
23
LED (Serial Tx)
24
LED (Serial Rx)
LED NO.
Description
1
Power
2
Ethernet Act
3
Ethernet Link
4
Serial Rx/Tx (2-color)
5
Ready
