Text mode
Original mode

103

TFTP Boot image(ps110a.img) loading at 0xb00000.. 3019495 Bytes
3019495 bytes receive done.
kernel upgrade start.
Kernel Block : Write to Flash... done
kernel upgrade complete.
Cramfs upgrade start.
Cramfs Block : Write to Flash... done
Cramfs upgrade complete.
Configuration upgrade start.
Configuration Block : Write to Flash... done
Configuration upgrade complete.

Firmware upgrade is finished successfully..

-----------------------------------------------------------------------------

Firmware upgrade

-----------------------------------------------------------------------------

Select menu
1. Protocol [TFTP]
2. IP address assigned to Ethernet interface [192.168.161.5]
3. Server’s IP address [192.168.0.128]
4. Firmware File Name [ps.img]
5. Start firmware upgrade

Back, Refresh

----->

Figure A-15 Firmware upgrade process

After finishing the firmware upgrade process, the program will display the main menu along with a

success message.
