15

Figure 2.8 Quick connect dialog box

2.4 Restoring Factory Default

Users may restore the Rhio232 parameters into factory default value by pressing factory reset

switch on the hole of the Rhio232 side panel. They will have to put the sharp pin into the hole

and press it for around 1 sec to reset the Rhio232. The Rhio232 will be rebooted after the

operation.

The following is the factory default value of the parameters.

I/O Port status:

Enable

ADC Operation mode : Level Mode

Power-out Post Recovery: Enable

ADC Threshold value : 512

Output Port operation condition : None

Run/Stop status : Run
