3: Operating Instructions
10 000-10000-080-02-201207
Turning the Lamp Off
Turn the Xenon lamp off by holding the Xenon ON/OFF switch down for one full second. The Status
LED blinks for about 30 seconds while the lamp cools down.
Warming Up the Lamp
The HPX-2000 requires 25-30 minutes of operation to reach a state of thermal equilibrium. During this
warm-up period, the intensity of the output power can vary substantially.
If applications require extreme intensity stability, the lamp should be warmed up for an additional 30-45
minutes. Once warmed up for this amount of time, the lamp will reach specified drift values.
Operating the TTL Shutter
Automatic Operation
For automatic operation, plug the SUB-D 15-pin TTL connector into the appropriate socket on your
spectrometer.
Manual Operation
Manually set the operating mode of the HPX-2000 with the Shutter Switch as follows:
• OPEN - Shutter open
• CLOSE - Shutter closed
• TTL - Controlled over external TTL signal (HIGH=OPEN, LOW=CLOSE)
Operating the Filter Slit
►
Procedure
1. Rotate the light beam protection cap to open the filter slit (see Front Panel ).
2. Insert your filter with a maximum size of 1” round or square into the filter slit.
3. Rotate the light beam protection cap to close the filter slit.
