Macro-Tech 5000VZ Power Amplifier
Reference Manual
P.I.P.–ISO is designed especially for 25 to 140 volt distrib-
uted systems where UL
® -listed isolation is required. Installa-
tion requires minor amplifier modifications. With the P.I.P.–ISO
installed, the amplifier outputs are safely isolated from the
input terminals and the chassis.
P.I.P.–ATNB uses balanced 1:1 transformers to isolate the
amplifier from the input signal. It also includes 12 dB/octave
RFI filters, variable 18 dB/octave high-pass filters, and 6 dB/
octave 3 kHz shelving networks for “constant-directivity” horn
equalization. The module also includes a calibrated 21-step
precision attenuator for each channel. Screw terminal plugs
are provided for input.
P.I.P.–XOV is a versatile 18 dB/octave mono crossover/filter
with biamping and triamping capabilities
IQ-PIP-USP2 is an IQ2-series component. This means it sup-
ports Crown’s UCODE protocol and requires an IQ System with
an IQ2-compatible IQ interface. UCODE (universal code) en-
ables users and third parties to develop custom software
objects to control and monitor
IQ2-compatible components
like the IQ-PIP-USP2.
P.I.P.–FMX facilitates “daisy-chaining” balanced amplifier in-
puts. Female to male three-pin XLR connectors are used to
passively bridge the inputs.
P.I.P.–PA adds a switchable balanced low-impedance mic
input, a balanced line-level input and a compressor to each
channel. Remote switching circuitry provides quick and quiet
fades from mic to line and back.
P.I.P.–BEQ is a two-channel module providing equalization
for BOSE
® loudspeakers. For example, the P.I.P.–BEQ can
be used in place of a BOSE 102 controller. Screw terminal
plugs provide balanced connections. Each input channel
has an output from the
PIP that can be independently config-
ured for output with no processing, loudspeaker equalization
or loudspeaker equalization with bass-cut.
P.I.P.–RPA adds the features of a 4x2 mixer to your amplifier.
Its four inputs accept mic- or line-level input. It offers priority
switching (“voice-over”) of each input and remote level con-
trol with the RPA–RMT. Other features include bus inputs and
outputs, adjustable input sensitivity, phantom power and RFI
suppression. Input isolation transformers are optional.
For more information on these or other PIPs under development, contact your local dealer or Crown’s Technical
Support Group.
