MA-5002VZ Power Amplifier
Operation Manual
3.4 Choose Input Wire
and Connectors
Refer to Figure 3.3 for correct connector pin
assignments for balanced wiring, and Figure 3.4
for correct connector pin assignments for unbal-
anced wiring.
NOTE: Custom wiring should only be
performed by qualified personnel.
Balanced Line
Unbalanced Line
Figure 3.3 Balanced Input
Connector Wiring
Figure 3.4 Unbalanced Input
Connector Wiring
3 Setup
(continued)
