MA-5002VZ Power Amplifier
Operation Manual
7 Specifications (continued)
Performance (continued)
Output Impedance See Figure 7.5
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
Parallel Mono 2-8 ohms
4-16 ohms
1-4 ohms
Voltage Gain (8-ohm load, rated output at 1 kHz, maximum level setting)
0.775V sensitivity
1.4V sensitivity
26 dB sensitivity 132:1 ±6% or 42 dB ±0.5 dB
71:1 ±6% or 37 dB ±0.5 dB
20:1 ±6% or 26 dB ±0.5 dB
Required AC Mains 50 or 60 Hz; 100-, 120-, 208-, 230-, 240-VAC (±10%).
Power Draw at Idle 90 watts or less
Construction
Cooling Internal heat sinks with on-demand, proportional forced-air
cooling controlled by ODEP. Includes custom heat diffusers
and patented circuitry to promote uniform dissipation.
Dimensions
Width
Height
Depth (behind mounting surface) EIA Standard 19-inch rack mount (EIA RS-310-B)
5.25 inch (13.3 cm)
15.875 inch (40.3 cm)
Weight
Center of gravity is 6 inches (15.2 cm) behind the front mounting surface.
Net
Shipping
77 pounds, 9 ounces (35.2 kg)
88 pounds, 10 ounces (40.2 kg)
