Input Label

Applies To

MPX-6, SMX-6, AMB-5

The input labels number both the mic/line inputs of all of the IQ mixer products and the expanded input
sections of the SMX-6 and the AMB-5. You can use this label to copy the settings of one input channel to
another channel. This is accomplished by "drag-and-drop:"

1) Click on the label of the input whose settings you wish to copy.

PRELIMINARY

2) While holding the mouse down, drag the cursor over the input section that you want to receive the
copied settings.
3) Release the mouse button.

Note that in the case of the SMX-6 and the AMB-5, the settings copied are only those related to the Auto
function designated by the

Auto Control Page

and not all of the settings.

Output Label

Applies To

MPX-6, SMX-6, AMB-5

The output labels number input sliders as belonging to the outputs, 1 or 2, of the mixer. The mic/line
inputs of all of the IQ mixer products and the Auto Control Pages of the SMX-6 include these labels. The
input designation 1 through 6 and the output designation 1 or 2 combine to give you a single input/output
channel (e.g. input 4 / output 2). You can use these labels to copy all of the settings of one input/output
channel to any other input/output channel. This is accomplished by "drag-and-drop:"

1) Click on the output label of the input/output channel whose settings you wish to copy.
2) While holding the mouse down, drag the cursor over the input/output section that you want to receive
the copied settings.
3) Release the mouse button.

Note that in the case of the SMX-6 and the AMB-5 the settings copied are only those related to the Auto
function designated by the

Auto Control Page

and not all of the settings.

Note: If you drag the settings of one input/output channel over the input label, then both outputs of that
input channel will be affected.


Data LED

Applies To

MPX-6, SMX-6, AMB-5

Every IQ mixer component is equipped with a data light that normally flashes only during those moments
when performing serial communications. This button will allow you to set it so the "Data" LED is fixed on.


Aux Out

Applies To
