Mixer/Multiplexer Control Panels
Mixer/Multiplexer Control Panel
The Mixer/Multiplexer Control Panel is a window within IQ for Windows that can be used to control any
of the set of Crown IQ-compatible mixer/multiplexer products: the MPX-6, the SMX-6 and the AMB-5.
Each of these products has several software controls in common. These include:
P
Aux Out switch
5 (the AMB-5) or 6 Mic/line inputs
"Data" LED switch
R
E
Aux In Indicator
2 Audio Bus switches
The Toolbar
2 User Labels
The Mixer/Multiplexers
L
MPX-6
I
M
The MPX-6 is a 6x2 mixer/multiplexer with six mic/line inputs, two main line level outputs and two
switchable bus outputs. Under computer control, it can switch the inputs on or off, control their levels, and
route them to two main and two bus outputs. Multiple MPX-6s can be connected together to create larger
systems.
I
6 Mic/line inputs
Software controls:
N
Aux Out switch
"Data" LED switch
Aux In Indicator
A
The Toolbar
2 Audio Bus switches
R
SMX-6
2 User Labels
Y
The SMX-6 is a sensing 6x2 mixer/multiplexer with six mic/line inputs, two main line-level outputs and two
switchable bus outputs. It contains a sensing circuit at the beginning of each input to sense the input
signal level ahead of any signal processing. Similar sensors are located at each output channel. These
sensors, along with its on-board intelligence, enable the SMX-6 to perform many versatile functions like
automatic mixing , compression, limiting and automatic level control. In addition an SMX-6 also has all the
manual switching and routing capabilities of an
MPX-6.
Software Controls:
6 Mic/line inputs
"Data" LED button
Aux Out button
Aux In Indicator
2 Audio Bus buttons
1 Auto button
