ScreenArray

®

PIP Modules

Page 5

Operation Manual

Important: Be careful when
attaching the ribbon cable to the
connector that the cable is properly
seated before applying pressure to
the connector.

Forcing the cable onto the connector
could cause the keying tabs, which
ensure proper pin alignment, to
break. Connecting the ribbon
cables with improper pin alignments
may result in damage to the

PIP

.

When both cables are firmly
attached, turn the PIP module back
to an upright position and insert into
the

PIP

opening in the back of the

amplifier. Take care while inserting
the

PIP

to make sure you do not

crimp, pinch or stretch the ribbon
cables.

3. Tighten the two PIP mounting

screws until the

PIP

is secured to the

amplifier back panel. Be sure to use
the supplied star-washers for
good ground connection.
