A.

C.

A.

Thread hose (1) into spray wand (2).

C.

Insert hose (1) into and through spout

sub-assembly (2).

3

1

2

1

Hose Installation

1

2

B.

B.

To allow for easier assembly, bend

hose near wand as shown.

Bend
