Replacement Parts 27831XXX
2
3
7
1
4
5
6
1 mounting set
40916000
2 slider
96505XXX
3 mounting piece 97597000
4 cylinder screw 97661000
5 set screw
97660000
6 wall support
97696XXX
7 hose
28276XXX
Replacement Parts 27834XXX
1 mounting set
96179000
2 support element 96341000
3 hexagon screw 97661000
4 pin
97546000
5 slider
96505XXX
6 hose
28276XXX
1
2
3
4
5
6
