Axor Citterio Wallbar Installation
Mark the positions for the screw holes (1). The center
of the top hole should be 36” from the center of the
bottom hole.
Drill the holes with a 6 mm bit suitable for the wall
surface (2).
Install the anchors. Seal the wall around the anchors
with waterproof sealant.
Install the mounting pieces with the screws and metal
washers.
Place the wallbar over the mounting pieces (1).
Tighten the set screws with a 3 mm Allen wrench (2).
