controller circuit board. It is labeled and located at the lower middle side of the printed circuit board, as
you face the component side of the board. It must be pressed and held down for at least three seconds.
To permanently change a dryer controller cycle, follow the procedure below. Things that are displayed on
the 4-digit numeric display will be in “quotation marks”. Keys on the touch pad that physically need to be
pressed will be in CAPITAL AND BOLD LETTERS.
If, at any time, you want to escape the permanent programming mode while changing the settings, you
can press the STOP key on the dryer controller touch pad if the 4-digit numeric display is not fl ashing. The
SELECT/ENTER key on the dryer controller touch pad can be pressed and released to enter the fl ashing
value shown on the 4-digit numeric display and allow you to escape.
Procedure
1. Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer controller will show
“LOAd” when the dryer is not in a dry cycle.
2. Press and release the PROG key on the dryer controller touch pad.
3. Press and release the UP arrow key on the dryer controller touch pad. The programming L.E.D. will
illuminate and the 4-digit numeric display on the dryer controller will change to “Prog”.
4. Press and release the UP or DOWN arrow keys to choose the dry cycle you want to change (dry cycle
1 through 5). The dry cycle L.E.D. will illuminate to indicate which dry cycle you are choosing. If you
press either arrow key and hold it down, the controller will sequence through the fi ve dry cycles.
5. Press and release the SELECT/ENTER key once you have chosen the dry cycle you want to change.
After you press this key, the dry time L.E.D. will illuminate. The dry cycle L.E.D. and the programming
L.E.D. will remain illuminated. The total dry time will also be displayed on the 4-digit numeric display.
6. Press and release the UP or DOWN arrow keys to change the total dry time. Once either of the arrow
keys is pressed, the dry time L.E.D. and the total dry time on the 4-digit numeric display will fl ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the total dry times available (1 through 60 minutes). This displayed dry time includes the cool
down time along with the heated time. To not change the total dry time, do not press the arrow keys.
Go to the next step.
7. Press and release the SELECT/ENTER key. Once this key is pressed and released, the dry time L.E.D.
will switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, and the temperature L.E.D.
will illuminate. The drying temperature will also be shown on the 4-digit numeric display.
Press and release the UP or DOWN arrow keys to change the drying temperature. Each press and release
of the arrow keys will either increase or decrease the temperature by fi ve degrees Fahrenheit or three de-
grees Celsius, depending on how your dryer controller is set up. Once either of the arrow keys is pressed,
the temperature L.E.D. and the drying temperature on the 4-digit numeric display will fl ash. If you press
and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow) your way
through the available drying temperatures (1050 Fahrenheit or 400 Celsius, up to 1950 Fahrenheit or 9(
Celsius). If you do not want to change the drying temperature, do not press the arrow keys. Go to the
next step.
Press and release the SELECT/ENTER key. Once this key is pressed and released, the temperature L.E.D.
will switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, and the cool down L.E.D. will
illuminate. The cool down time will also be shown on the 4-digit numeric display.
Press and release the UP or DOWN arrow keys to change the cool down time. Once either of the arrow
keys is pressed, the cool down L.E.D. and the cool down time on the 4-digit numeric display will fl ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the cool down times available (2 through 60 minutes). To not change the cool down time, do not
press the arrow keys. Go to the next step.
