9
FIGURE 5 - THOROUGHBRED 600 SPECIFICATIONS
MODEL WCN40AFH
CAPACITY 6 CUBIC FT.
(UP TO 40#)
CYLINDER DIM. 25" DIA. x 21 1/8" DEPTH
GROSS WEIGHT
NET WEIGHT
656 POUNDS
622 POUNDS
ELECTRICAL 208-240 VAC, 60 HZ, 1 PH OR 3 PH
EXTRACTION FORCE 100 g=s
WASH SPEED
SPIN SPEED 43 R.P.M.
531 R.P.M.
DRIVE SYSTEM SOFT START REVERSING AC MOTOR DRIVE
WATER INLET 2 SOLENOID OPERATED VALVES
FLOW RATE, 9 GAL./MIN. EACH
FLOW PRESSURE, 30-120 PSI
DRAIN VALVE 3" OUTSIDE DIAMETER
PROGRAM CYCLES 30 USER PROGRAMMABLE CYCLES
(29 OF 30 PREPROGRAMMED AT THE FACTORY)
CYCLES TAILORED FOR SHIRT LAUNDRY,
HOTEL/HOTEL, HEALTH CARE AND FOOD & BEVERAGE
(SEE PRESET CYCLE INFORMATION TABLE)
TEST CYCLE DIAGNOSTIC TEST PROGRAM
TEMPERATURES USER SELECTABLE FROM 4 SETTINGS
MACHINE CONTROL:
KEYLOCK ADVANCE/RUN/PROGRAM
MEMBRANE STOP/EXIT
START/ENTER
SCROLL UP
SCROLL DOWN
FIGURE 6 - WATER USAGE
USAGE/BATH LOW LEVEL HIGH LEVEL
FILL FILL
EMPTY CYLINDER - NO LOAD 12.6 gals. 18.6 gals.
FULL CYLINDER - LOADED
Water required to fill bath gals. gals.
starting with a dry load.
Water required to fill bath preceded 10.6 gals. 16.4 gals.
by a drain without a spin.
Water required to fill bath preceded gals. 21.4 gals.
by a drain with a spin.
