10
OPERATING CONTROLS
There are four (4) switches that control the washer operation. Each switch is
shown below followed by an explanation of each switch.
Figure 7 - Push-button Control Switches
STOP (RED) Push-button - Depress momentarily.
Stops the washer during the cycle. All washer cycle information is retained,
the door remains locked and the water remains in the tub.
STOP (RED) Push-button - Depress and hold for 3 seconds or longer.
Stops the washer and clears the cycle. All washer cycle information is
cleared, the water is drained and the door is unlocked. The washer is ready
for the next wash cycle.
NOTE: The door lock safety mechanism will prevent the door from opening for up
to 3 mins. when the washer is stopped during a cycle and the cycle
cleared.
WARNING
DEPRESSING AND HOLDING THE STOP IS AN EMERGENCY STOP BUTTON.
THIS DOES NOT DISCONNECT THE MACHINE FROM THE INPUT POWER.
START (GREEN) Push-button - Depress momentarily.
Starts the cycle shown on the display. If the cycle was stopped in the middle,
depressing the START will begin the cycle from the point at which the cycle was
stopped.
SCROLL UP ARROW (BLUE) Push-button - Depress momentarily / depress and hold.
Scroll Up increases the cycle number displayed by one each time the switch is
depressed. When the Scroll Up is held, the display cycle numbers will continue
to increase until cycle # 30 (cycle # 31 in Programming Mode) is reached at
which time the cycle number displayed will rollover back to cycle # 1.
SCROLL DOWN ARROW (BLUE) Push-button - Depress momentarily / depress and hold.
Scroll Down decreases the cycle number displayed by one each time the switch is
depressed. When the Scroll Up is held, the display cycle numbers will continue
to decrease until cycle # 1 is reached at which time the cycle number displayed
will rollover to cycle # 30 (cycle # 31 in Programming Mode).
