TOUCH PAD DESCRIPTION
INDICATOR LIGHTS (L.E.D.s)
Description
Cycle (1 through 5) These L.E.D.s are on solid when a particular cycle is chosen for
operation or programming.
Gas Valve
This L.E.D. is part of the 4-digit numeric display and will be on
solid during the drying part of a cycle when the gas valve does not
need to be on. The L.E.D. will be blinking when the gas valve needs
to be on. The L.E.D. will not be on solid or blinking (off) if the
cycle is stopped, complete, in cool down, or terminated.
Programming
These L.E.D.s are on solid as they are selected during the
programming of the dryer controller.
Stop
This L.E.D. is on solid when either the STOP button is pressed once
or the door is opened during an operating cycle.
SWITCHES (Pushbuttons)
Description
This touch pad switch will increment (increase) dry time, cool down
time, and drying temperature. It will also scroll upwards when
Up/Increase selecting a dry cycle.
This touch pad switch will decrement (decrease) dry time, cool
down time and drying temperature. It will also scroll downwards
Down/Decrease when selecting a dry cycle.
This touch pad switch allows the dryer controller to enter the
permanent programming mode.
Program
This touch pad switch will select one of the three variable parts of
the dry cycle (dry time, temperature, or cool down) by sequencing
through them. Once one of the variable parts of the dry cycle is
Select/Enter chosen and changed, this touch pad switch will enter the new
(changed) value into the dry cycle program.
