1mm & 1.27mm Center - Spring Probe Specification
Operating Temperature
Continuous usage: -40°C to +150°C
Mechanical Specifications
Individual spring pin force
30g (1.1oz) at 0.098” (2.49mm) recommended operating position
Spring pin cycle life
500,000 cycles
Electrical Specifications
P-P112A / P-P138A
P-P127A
Contact resistance:
27.38m
Ω 28.19mΩ
Self Inductance:
0.62nH
0.70nH
Mutual Inductance:
0.065nH
Cross talk:
<-10dB to 8GHz
<0.5dB to 4.1GHz
Insertion loss:
<1 dB to 10GHz
Rise time
24.6 ps
Pin to ground Capacitance:
0.45pF
Pin to pin Capacitance:
0.042pF
Current carrying capacity:
4A
4.5A
0.8mm Center - Spring Probe Specification
Operating Temperature
Continuous usage: -40°C to +120°C
Mechanical Specifications
Individual spring pin force
22g (0.8oz) at 0.162” (4.11mm) recommended operating position
Spring pin cycle life
500,000 cycles
Electrical Specifications
P-P114A
Contact resistance:
18.62m
Ω
Self Inductance:
0.84nH
<1dB to 6.7 GHz
Insertion loss:
<3dB to 12 GHz
Pin to ground Capacitance:
0.76pF
Pin to pin Capacitance:
0.068pF
Current carrying capacity:
3A
0.5mm Center - Spring Probe Specification
Operating Temperature
Continuous usage: -40°C to +150°C
Mechanical Specifications
Individual spring pin force
