DC-DC Converters

PS2 Series

1.5 Watt PCB Mounting

Single & Dual Outputs

Features

24-Pin DIP Package

Regulated Outputs

50% Efficiency

Pi Input Filter

Low Ripple and Noise

SMD Mounting Versions Available

- Consult Sales Office for Details

MODEL

INPUT

OUTPUT

OUTPUT

INPUT CURRENT

VOLTAGE

VOLTAGE

CURRENT

NO LOAD

FULL LOAD

PS2-05-05S

5 VDC

300 mA

620 mA

PS2-05-12S

12 VDC

125 mA

550 mA

PS2-05-15S

5 VDC

15 VDC

100 mA

110 mA

550 mA

PS2-05-12D

+12 VDC

+60 mA

550 mA

PS2-05-15D

+15 VDC

+50 mA

550 mA

PS2-12-05S

5 VDC

300 mA

260 mA

PS2-12-12S

12 VDC

125 mA

215 mA

PS2-12-15S

12 VDC

15 VDC

100 mA

40 mA

215 mA

PS2-12-12D

+12 VDC

+60 mA

215 mA

PS2-12-15D

+15 VDC

+50 mA

215 mA

PS2-24-05S

5 VDC

300 mA

130 mA

PS2-24-12S

12 VDC

125 mA

115 mA

PS2-24-15S

24 VDC

15 VDC

100 mA

20 mA

115 mA

PS2-24-12D

+12 VDC

+60 mA

115 mA

PS2-24-15D

+15 VDC

+50 mA

115 mA

PS2-28-05S

5 VDC

300 mA

110 mA

PS2-28-12S

12 VDC

125 mA

100 mA

PS2-28-15S

28 VDC

15 VDC

100 mA

20 mA

100 mA

PS2-28-12D

+12 VDC

+60 mA

100 mA

PS2-28-15D

+15 VDC

+50 mA

100 mA

PS2-48-05S

5 VDC

300 mA

65 mA

PS2-48-12S

12 VDC

125 mA

60 mA

PS2-48-15S

48 VDC

15 VDC

100 mA

15 mA

60 mA

PS2-48-12D

+12 VDC

+60 mA

60 mA

PS2-48-15D

+15 VDC

+50 mA

60 mA
