Powersolve TOS Series - Manual

www.powersolve.co.uk
Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England
Tel:01635 521858 Fax: 01635 523771 Email: [email protected]
Order Code Input voltage Output voltage Output current
SM-version range range max.
TOS 06-05SM 6 A
TOS 10-05SM 2.4 – 5.5 VDC 0.75 – 3.3 VDC 10 A
TOS 16-05SM 16 A
TOS 06-12SM 6 A
TOS 10-12SM 8.3 – 14.0 VDC 0.75 – 5.0 VDC 10 A
TOS 16-12SM 16 A
Order code Input voltage Output voltage Output current
SIL-version range range max.
TOS 06-05SIL 6 A
TOS 10-05SIL 2.4 – 5.5 VDC 0.75 – 3.3 VDC 10 A
TOS 16-05SIL 16 A
TOS 06-12SIL 6 A
TOS 10-12SIL 8.3 – 14.0 VDC 0.75 – 5.0 VDC 10 A
TOS 16-12SIL 16 A
• High Power Density: Models with 6, 10 and 16A
• Programmable Output Voltage from 0.75 to 5.0 VDC
• Very high Efficiency up to 96%
• Input Voltage 5 or 12 VDC
• Remote On/Off
• Input Under-voltage Lockout
• Over Temperature Protection
• Surface Mount (SM) or SIL-Version
• Surface Mount Version fully compatible with DOSA Standard
DC-DC Switching Regulators
TOS Series
Point of Load (POL) Converters
Models
Line regulation: ±0.3% max.
Load regulation: ±0.4% max.
Output voltage: programmable by external resistor
Ripple & Noise: <50 mVpk-pk (with output capacitors)
Transient response time: 50 µsec. typ. (50% load change)
Short circuit protection: continuous, automatic recovery
Efficiency: 93% typ.
Operating temperature range: –40°C … +85°C
Remote On/Off: negative logic shutdown input for
standby mode
Input under-voltage lockout: – shutdown at 2.0 VDC resp. 7.8 VDC
– startup at 2.2 VDC resp. 7.9 VDC
10.2 (0.40)
22.9 (0.90)
3.29 (0.13)
20.32 (0.8)
Vi
n
GND Prog Vo
ut
On/Of
f
6 A output Models
Single-in-line (SIL-Version)
Vi
n
GND Prog Vo
ut
On/Of
f
0.70
(0.028)
6.65
(0.26)
10A & 16A output models
Sens No Pin
0.64
(0.025)
0.51
(0.02)
1.28
(0.05)
3.24 (0.128)
1.18
(0.046)
8.28
(0.33)
0.51
(0.02)
0.64
(0.025)
1.28
(0.05)
5 x 2.54 (5 x 0.10) 4 x 2.54 (4 x 0.10)
50.8 (2.00)
12.7 (0.50)
25.4 (1.0)
Vi
n
Vo
ut
Vo
ut
GND
2.54 (0.1)
15.24 (0.6)
17.78 (0.7)
() = Inches
1.5
11
.4 (0.45)
2.29
20.3 (0.8)
(0.09) (0.05)
1.3
1.57
8.9 (0.35)
(0.82)
4.06
(0.16)
4.06
(0.16)
4.57
(0.18)
17.52 (0.69)
(0.06)
8.64 (0.34)
Vin
GND Prog Vout
On/Off
1.57
(0.82)
5.97
(0.24)
Bottom View
6 A output Models
1.9
13.5 (0.53)
2.84
33.0 (1.3)
(0.112) (0.05)
1.3
1.57
10.92 (0.43)
(0.82)
4.83
(0.19)
4.83
(0.19)
7.54
(0.30)
29.9 (1.18)
(0.075)
10.29 (0.41)
Vin
GND Prog Vout
On/Off
1.57
(0.82)
8.28
(0.33)
Bottom View
10A & 16A output models
4.83
(0.19)
4.83
(0.19)
Sens No Pin
Surface Mount (SM-Version)
